HDPE Pipes

Reliable HDPE Pipes for High-Performance Water & Infrastructure Networks

Vinayak HDPE Pipes are manufactured using premium-grade High-Density Polyethylene (HDPE) material to provide exceptional strength, flexibility, and long-term performance. These pipes are widely used in water transmission, industrial utilities, infrastructure projects, and underground pipeline networks where reliability and durability are essential.

  • Manufactured Using Advanced High-Density Polyethylene Technology
  • Suitable for Long-Distance Pipeline Installations
  • Ideal for Underground and Surface Network Applications
  • Supports Modern Infrastructure and Utility Projects
  • Designed for Reliable Long-Term Operational Performance

Why Choose Vinayak HDPE Pipes?

Exceptional Flexibility

The flexible pipe structure allows easy installation across uneven terrain and challenging project environments while reducing the risk of structural damage.

High Impact Strength

Engineered to withstand external loads, transportation handling, and installation stresses, ensuring dependable performance throughout the pipeline lifecycle.

Fusion Joint Technology

HDPE pipes can be joined using advanced fusion methods that create strong and reliable pipeline systems suitable for critical applications.

Environmental Stress Resistance

Designed to perform efficiently under varying environmental conditions, making them ideal for long-term outdoor and underground installations.

HDPE Pipes

SIZES SDR – 41 SDR – 33 SDR – 26 SDR – 21 SDR – 17 SDR – 13.6 SDR – 11 SDR – 9 SDR – 7.4 SDR – 6
PE 63 PN 2 PE 63 PN 2.5 PE 63 PN 3.2 PE 63 PN 4 PE 63 PN 5 PE 63 PN 6 PE 63 PN 8 – – –
PE 80 PN 2.5 PE 80 PN 3.2 PE 80 PN 4 PE 80 PN 5 PE 80 PN 6 PE 80 PN 8 PE 80 PN 10 PE 80 PN 12.5 PE 80 PN 16 PE 80 PN 20
PE 100 PN 3 PE 100 PN 4 PE 100 PN 5 PE 100 PN 6 PE 100 PN 8 PE 100 PN 10 PE 100 PN 12.5 PE 100 PN 16 PE 100 PN 20 –
Wall Thickne. Wall Thickne. Wall Thickne. Wall Thickne. Wall Thickne. Wall Thickne. Wall Thickne. Wall Thickne. Wall Thickne. Wall Thickne.
Min. Max. Min. Max. Min. Max. Min. Max. Min. Max. Min. Max. Min. Max. Min. Max. Min. Max. Min. Max.
16 – – – – – – – – – – – – – – 2.00 2.30 2.20 2.60 2.70 3.10
20 – – – – – – – – – – – – 2.00 2.30 2.30 2.70 2.80 3.20 3.40 3.90
25 – – – – – – – – – – 2.00 2.30 2.30 2.70 2.80 3.20 3.40 3.90 4.20 4.80
32 – – – – – – – – 2.00 2.30 2.40 2.80 3.00 3.40 3.60 4.10 4.40 5.00 5.40 6.10
40 – – – – – – 2.00 2.30 2.40 2.80 3.00 3.40 3.70 4.20 4.50 5.10 5.50 6.20 6.70 7.50
50 – – – – 2.00 2.30 2.40 2.80 3.00 3.40 3.70 4.20 4.60 5.20 5.60 6.30 6.80 7.60 8.40 9.40
63 – – – – 2.50 2.90 3.00 3.40 3.80 4.30 4.70 5.30 5.80 6.50 7.00 7.80 8.60 9.60 10.50 11.70
75 2.00 2.30 2.30 2.70 2.90 3.30 3.60 4.10 4.50 5.10 5.60 6.30 6.90 7.70 8.40 9.40 10.20 11.40 12.50 13.90
90 2.20 2.60 2.80 3.20 3.50 4.00 4.30 4.90 5.30 6.00 6.70 7.50 8.20 9.20 10.00 11.10 12.20 13.60 15.00 16.60
110 2.70 3.10 3.40 3.90 4.30 4.90 5.30 6.00 6.50 7.30 8.10 9.10 10.00 11.10 12.30 13.70 14.90 16.50 18.40 20.40
125 3.10 3.60 3.80 4.30 4.90 5.50 6.00 6.70 7.40 8.30 9.20 10.30 11.40 12.70 13.90 15.40 16.90 18.70 20.90 23.10
140 3.50 4.00 4.30 4.90 5.40 6.10 6.70 7.50 8.30 9.30 10.30 11.50 12.80 14.20 15.60 17.30 19.00 21.00 23.40 25.90
160 4.00 4.50 4.90 5.50 6.20 7.00 7.70 8.60 9.50 10.60 11.80 13.10 14.60 16.20 17.80 19.70 21.70 24.00 26.70 29.50
180 4.40 5.00 5.50 6.20 7.00 7.80 8.60 9.60 10.60 11.80 13.30 14.80 16.40 18.20 20.00 22.10 24.40 27.00 30.00 33.10
200 4.90 5.50 6.10 6.90 7.70 8.60 9.60 10.70 11.80 13.10 14.80 16.40 18.20 20.20 22.30 24.70 27.10 30.00 33.40 36.90
225 5.50 6.20 6.90 7.70 8.70 9.70 10.80 12.00 13.30 14.80 16.60 18.40 20.50 22.70 25.00 27.60 30.50 33.70 37.50 41.40
250 6.10 6.90 7.60 8.50 9.70 10.80 12.00 13.30 14.80 16.40 18.40 20.40 22.80 25.20 27.80 30.70 33.80 37.30 41.70 46.00
280 6.90 7.70 8.50 9.50 10.80 12.00 13.40 14.90 16.50 18.30 20.60 22.80 25.50 28.20 31.20 34.50 37.90 41.80 46.70 51.50
315 7.70 8.60 9.60 10.70 12.20 13.60 15.00 16.60 18.60 20.60 23.20 25.70 28.70 31.70 35.00 38.60 42.60 47.00 52.50 57.90
355 8.70 9.70 10.80 12.00 13.70 15.20 17.00 18.80 20.90 23.10 26.20 29.00 32.30 35.70 39.50 43.60 48.00 52.90 59.20 65.30
400 9.80 10.90 12.20 13.60 15.40 17.10 19.10 21.20 23.60 26.10 29.50 32.60 36.40 40.20 44.50 49.10 54.10 59.70 66.70 73.50
450 11.00 12.20 13.70 15.20 17.40 19.30 21.50 23.80 26.50 29.30 33.10 36.60 41.00 45.20 50.00 55.10 60.90 67.10 75.00 82.60
500 12.20 13.60 15.20 16.90 19.30 21.40 23.90 26.40 29.50 32.60 36.80 40.60 45.50 50.20 55.60 61.30 67.60 74.50 83.40 91.90
560 13.70 15.20 17.00 18.80 21.60 23.90 26.70 29.50 33.00 36.40 41.20 45.50 51.00 56.20 62.30 68.70 75.70 83.40 93.40 102.90
630 15.40 17.10 19.10 21.20 24.30 26.90 30.00 33.10 37.10 41.00 46.40 51.20 57.30 63.20 70.00 77.10 85.20 93.90 105.00 115.60

Application

Municipal Water Supply Systems

Used for city and municipal water distribution networks requiring durable and long-lasting pipeline solutions.

Underground Utility Networks

Suitable for underground pipeline infrastructure where reliability and operational safety are critical.

Industrial Fluid Transportation

Ideal for industrial facilities requiring efficient transportation of water and process fluids.

Mining & Construction Projects

Supports demanding mining operations and construction infrastructure applications.

Infrastructure Development Projects

Widely used in public utility, urban development, and large-scale infrastructure projects.

Wastewater & Drainage Systems

Suitable for wastewater conveyance and drainage applications requiring durable pipeline performance.
